OsmaW ABS Double Socket GY 32
| 1 bag | 10 pieces |
|---|
Product Identifiers
Catalog Code4Z104G
EAN Number5011479110263
SAP number3034990
| 1 bag | 10 pieces |
|---|
| Label | Value |
|---|---|
Max. operating pressure at max. medium temperature | 0bar |
Zeta value | 0 |
Eccentric | No |
Shape | Straight |
Connection 1 | Plastic welded end |
Bend radius | 0mm |
Nominal diameter connection 1 | DN 32 |
Reducing | No |
Outer pipe diameter connection 2 | 41mm |
KIWA certified | Yes |
Nominal diameter connection 2 | DN 32 |
Connection 2 | Plastic welded end |
With thermal insulation | No |
Length | 42mm |
Capped | No |
Working length connection 1 | 0mm |
Wall thickness, connection 2 | 2.2mm |
Working length connection 2 | 0mm |
Surface protection connection 1 | Untreated |
Bend angle | 0° |
With sealing rings/gaskets | No |
ETIM Classification | EC003024 |
Main colour fitting | Grey |
Wall thickness, connection 1 | 2.2mm |
Length of connection 2 | 20mm |
Material quality connection 1 | Other |
Length of connection 1 | 20mm |
Medium temperature (continuous) | 0 |
Standard Dimension Ratio (SDR) | 0 |
Surface protection connection 2 | Untreated |
Surface treatment connection 2 | Untreated |
Material quality connection 2 | Other |
Material connection 2 | Acrylonitrile butadiene styrene (ABS) |
System-specific | No |
Surface treatment connection 1 | Untreated |
Model | 1-part |
Max. operating pressure at 20 °C | 0bar |
Outer pipe diameter connection 1 | 41mm |
Material connection 1 | Acrylonitrile butadiene styrene (ABS) |
Wrench width | 0mm |
Wrench width union nut | 0mm |
