PP E-Coupler Typ I 90 SDR11
| 1 BX | 18 штук |
|---|---|
| 1 PF | 432 штук |
Product Identifiers
Catalog CodeENA090XXXX
EAN Number7611704322454
SAP number4025182
| 1 BX | 18 штук |
|---|---|
| 1 PF | 432 штук |
| Label | Value |
|---|---|
ETIM Classification | EC003024 |
Material connection 1 | Polypropylene (PP) |
Material quality connection 1 | Other |
Surface protection connection 1 | Untreated |
Surface treatment connection 1 | Untreated |
Material connection 2 | Polypropylene (PP) |
Material quality connection 2 | Other |
Surface protection connection 2 | Untreated |
Surface treatment connection 2 | Untreated |
Shape | Other |
Model | 1-part |
Bend angle | 0° |
Bend radius | 0mm |
Reducing | No |
Eccentric | No |
System-specific | Yes |
Nominal diameter connection 1 | DN 90 |
Outer pipe diameter connection 1 | 0mm |
Wall thickness, connection 1 | 0mm |
Connection 1 | Electric welded sleeve |
Nominal diameter connection 2 | DN 90 |
Outer pipe diameter connection 2 | 90mm |
Wall thickness, connection 2 | 0mm |
Connection 2 | Electric welded sleeve |
Main colour fitting | Black |
Zeta value | 0.0000 |
Length | 0mm |
Length of connection 1 | 114mm |
Working length connection 1 | 168.4mm |
Length of connection 2 | 114mm |
Working length connection 2 | 0mm |
Wrench width | 0mm |
Wrench width union nut | 0mm |
Medium temperature (continuous) | 20 - 90 |
Max. operating pressure at 20 °C | 0bar |
Max. operating pressure at max. medium temperature | 0bar |
With thermal insulation | No |
Ring stiffness class | Other |
Standard Dimension Ratio (SDR) | 0.0000 |
Capped | No |
