Tigris M5 DRL Toilet Tank T-16x1/2"
| 1 bag | 5 pieces |
|---|---|
| 1 box | 25 pieces |
| 1 pallet | 1500 pieces |
Product Identifiers
Catalog Code
EAN Number4026294898242
SAP number4064292
| 1 bag | 5 pieces |
|---|---|
| 1 box | 25 pieces |
| 1 pallet | 1500 pieces |
| Label | Value |
|---|---|
ETIM Classification | EC003025 |
Material connection 1 | Brass |
Material quality connection 1 | Other |
Surface protection connection 1 | Untreated |
Surface treatment connection 1 | Untreated |
Material connection 2 | Brass |
Material quality connection 2 | Other |
Surface protection connection 2 | Untreated |
Surface treatment connection 2 | Untreated |
Material connection 3 | Brass |
Material quality connection 3 | Other |
Surface protection connection 3 | Untreated |
Surface treatment connection 3 | Untreated |
Model | T-piece |
Angle | 90° |
Reducing | Yes |
Multi-part | No |
System-specific | Yes |
Nominal diameter connection 1 | DN 12 |
Outer pipe diameter connection 1 | 16mm |
Wall thickness, connection 1 | 2mm |
Connection 1 | Press sleeve |
Contour code connection 1 | Several |
Nominal diameter connection 2 | 1/2 inch (15) |
Outer pipe diameter connection 2 | 21.2mm |
Wall thickness, connection 2 | 2.25mm |
Connection 2 | Press sleeve |
Contour code connection 2 | Several |
Nominal diameter connection 3 | DN 12 |
Outer pipe diameter connection 3 | 16mm |
Wall thickness, connection 3 | 2mm |
Connection 3 | Press sleeve |
Contour code connection 3 | Several |
Material sealing | Ethylene-propylene diene monomer rubber (EPDM) |
Main colour fitting | Brass |
Length of connection 1 | 25.5mm |
Working length connection 1 | 25.5mm |
High tensile strength | Yes |
Length of connection 2 | 0mm |
Working length connection 2 | 17mm |
Length of connection 3 | 25.5mm |
Working length connection 3 | 25.5mm |
Wrench width | 22mm |
Max. operating pressure at 20 °C | 10bar |
Wrench width union nut | 0mm |
Max. operating pressure at max. medium temperature | 6bar |
Medium temperature (continuous) | 0 |
Standard Dimension Ratio (SDR) | 0.0000 |
With sealing rings/gaskets | Yes |
With drain valve | No |
With de-aerator | No |
With thermal insulation | No |
With buffer stud | Yes |
Capped | No |
Zeta value branch fluent separation according to DVGW W 575 | 0.0000 |
Zeta value gangway current separation according to DVGW W 575 | 0.0000 |
Zeta value counter current separation according to DVGW W 575 | 0.0000 |
Zeta value branch merging flow according to DVGW W 575 | 0.0000 |
Zeta value passage merging flow according to DVGW W 575 | 0.0000 |
Zeta value counter merging flow according to DVGW W 575 | 0.0000 |
Gastec QA mark | No |
