PPR Elbow 45° WT 32
PRODUCT IDENTIFIERS
- EAN Number
- 8680099037136
- SAP number
- 3050937
PACKAGING DETAILS
- 1 bag20 pieces
- 1 box120 pieces
- 1 pallet7200 pieces
| Label | Value |
|---|---|
High tensile strength | No |
Flange compression class (BS) | EF018224_EV000154 |
Wrench width union nut | 0mm |
ULC quality mark | No |
Material connection 1 | EF025616_EV001608 |
Standard Dimension Ratio (SDR) | 6 |
Material quality connection 2 | EF025619_EV020815 |
DVGW quality mark for water | No |
Medium temperature (continuous) | 0 - 75 |
Surface protection connection 1 | EF010671_EV006034 |
Max. operating pressure at 20 °C | 20bar |
Wrench width | 0mm |
Model | EF000010_EV009555 |
DVGW quality mark for gas | No |
Surface protection connection 2 | EF010673_EV006034 |
Outer pipe diameter connection 2 | 43mm |
Working length connection 2 | 7mm |
Flange compression class (JIS) | EF018223_EV000154 |
KIWA certified | No |
Gastec QA - AR 214 (H2) | No |
Length of connection 1 | 32mm |
Length | 0mm |
Connection 2 | EF000322_EV005758 |
Bend radius | 0mm |
Material connection 2 | EF025617_EV001608 |
Zeta value | 1.5 |
Type approval according to BBR/EKS | No |
Material quality connection 1 | EF025618_EV020815 |
Gastec QA mark | No |
Reducing | No |
Working length connection 1 | 7mm |
Outer pipe diameter connection 1 | 43mm |
Shape | EF000051_EV020063 |
Surface treatment connection 1 | EF010672_EV006034 |
UL quality mark | No |
Nominal diameter connection 2 | EF020052_EV005922 |
With sealing rings/gaskets | Yes |
Bend angle | 45° |
Main colour fitting | EF016081_EV000202 |
With approval for TÜV | No |
KOMO certified | No |
Surface treatment connection 2 | EF010674_EV006034 |
Flange compression class (PN) | EF018222_EV000154 |
Flange compression class (ANSI) | EF018221_EV000154 |
System-specific | No |
Wall thickness, connection 2 | 5.5mm |
Nominal diameter connection 1 | EF023193_EV005922 |
Length of connection 2 | 25mm |
Connection 1 | EF000321_EV005758 |
Eccentric | No |
Wall thickness, connection 1 | 5.5mm |
DIN-CERTCO certificate | No |
ETIM Classification | EC003024 |
