| Label | Value |
|---|---|
Wrench width union nut | 0mm |
Surface treatment connection 2 | Untreated |
With approval for TÜV | No |
Model | 1-part |
Wall thickness, connection 2 | 6.5mm |
Standard Dimension Ratio (SDR) | 11 |
System-specific | No |
DVGW quality mark for gas | No |
Wall thickness, connection 1 | 6.5mm |
ETIM Classification | EC003024 |
Connection 2 | Welding connection |
DVGW quality mark for water | No |
Flange compression class (PN) | Other |
Length | 71mm |
Surface protection connection 1 | Untreated |
Bend radius | 0mm |
Length of connection 1 | 35.5mm |
Connection 1 | Welding connection |
Material quality connection 2 | PP-R |
Main colour fitting | Green |
Material connection 1 | Polypropylene (PP) |
Bend angle | 0° |
UL quality mark | No |
High tensile strength | No |
Wrench width | 0mm |
Nominal diameter connection 1 | DN 40 |
Material quality connection 1 | PP-R |
Outer pipe diameter connection 1 | 53mm |
Flange compression class (JIS) | Other |
With sealing rings/gaskets | Yes |
Working length connection 1 | 35.5mm |
Gastec QA mark | No |
Medium temperature (continuous) | 0 - 75 |
Zeta value | 0.55 |
Eccentric | No |
KOMO certified | No |
Length of connection 2 | 35.5mm |
DIN-CERTCO certificate | No |
Flange compression class (BS) | Other |
Outer pipe diameter connection 2 | 52.4mm |
Working length connection 2 | 35.5mm |
Surface protection connection 2 | Untreated |
Surface treatment connection 1 | Untreated |
Material connection 2 | Polypropylene (PP) |
KIWA certified | No |
Reducing | No |
ULC quality mark | No |
Shape | Straight |
Flange compression class (ANSI) | Other |
Gastec QA - AR 214 (H2) | No |
Type approval according to BBR/EKS | No |
Max. operating pressure at 20 °C | 10.0000EU570056 |
Nominal diameter connection 2 | DN 40 |
