HEPVO sifona līkums 32mm
Product Identifiers
Wavin kataloga kods
EAN numurs5027888170002
SAP numurs3018907
Commercial
| Label | Value |
|---|---|
| Wavin forma | Adaptors |
| Label | Value |
|---|---|
| ETIM Classification | EC003024 |
| Material connection 1 | Polypropylene (PP) |
| Surface protection connection 1 | Untreated |
| Surface treatment connection 1 | Untreated |
| Material connection 2 | Polypropylene (PP) |
| Surface protection connection 2 | Untreated |
| Surface treatment connection 2 | Untreated |
| Modelis | 2-part |
| Angle of bow | 90° |
| Izliektības diapazons | 0mm |
| Samazināšana | No |
| Ekscentrisks | No |
| Uz sistēmu orientēts | No |
| Nominal inner diameter connection 1 | DN 32 |
| Outer pipe diameter connection 1 | 34.8mm |
| Sienas biezums, savienojums 1 | 2.2mm |
| Savienojuma 2 nominālais iekšējais diametrs | DN 32 |
| Outer pipe diameter connection 2 | 34.8mm |
| Sienas biezums, savienojums 2 | 2.2mm |
| Main colour fitting | White |
| Zeta vērtība | 0.0000 |
| Length | 70mm |
| Savienojuma 1 garums | 33mm |
| Darba garums 1 | 0mm |
| Savienojuma 2 garums | 33mm |
| Darba garums 2 | 0mm |
| Uzgriežņa platums | 0mm |
| Swivel key size | 0mm |
| Maksimālais darba spiediens pie 20 C | 0bar |
| Max. operating pressure at max. medium temperature | 0bar |
| Ar siltumizolāciju | No |
| Standard Dimension Ratio (SDR) | 0.0000 |
| With packings | Yes |
| Ar vāku | No |
