Brass Tee 1/2" M/M
Product Identifiers
Catalog Code+0660602
EAN Number5708525408091
VVS nr.045435304
SAP number4055022
Commercial
| Label | Value |
|---|---|
| Wavin Shape | Tee |
| VVS nr. | 045435304 |
| Label | Value |
|---|---|
| ETIM Classification | EC003025 |
| Material connection 1 | Other |
| Material quality connection 1 | Dezincification resistant brass (DZR) |
| Surface protection connection 1 | Untreated |
| Surface treatment connection 1 | Untreated |
| Material connection 2 | Other |
| Material quality connection 2 | Dezincification resistant brass (DZR) |
| Surface protection connection 2 | Untreated |
| Surface treatment connection 2 | Untreated |
| Material connection 3 | Other |
| Material quality connection 3 | Dezincification resistant brass (DZR) |
| Surface protection connection 3 | Untreated |
| Surface treatment connection 3 | Untreated |
| Model | T-piece |
| Angle | 90° |
| Swept entry type (with inner radius) | Yes |
| Reducing | No |
| Multi-part | No |
| System-specific | Yes |
| Nominal diameter connection 1 | Other |
| Outer pipe diameter connection 1 | 0mm |
| Wall thickness, connection 1 | 2mm |
| Nominal diameter connection 2 | Other |
| Outer pipe diameter connection 2 | 0mm |
| Wall thickness, connection 2 | 2mm |
| Nominal diameter connection 3 | Other |
| Outer pipe diameter connection 3 | 0mm |
| Wall thickness, connection 3 | 2mm |
| Flange compression class | PN 10 |
| Main colour fitting | Yellow |
| Length of connection 1 | 24.5mm |
| Working length connection 1 | 0mm |
| High tensile strength | No |
| Length of connection 2 | 33.5mm |
| Working length connection 2 | 0mm |
| Length of connection 3 | 24.5mm |
| Working length connection 3 | 0mm |
| Wrench width | 0mm |
| Wrench width union nut | 0mm |
| Medium temperature (continuous) | 0.010 - 95 |
| Max. operating pressure at max. medium temperature | 10bar |
| Max. operating pressure at 20 °C | 10bar |
| Standard Dimension Ratio (SDR) | 0.0000 |
| With sealing rings/gaskets | No |
| With drain valve | No |
| With de-aerator | No |
| With thermal insulation | No |
| With buffer stud | No |
| Capped | No |
| FM quality mark | No |
| LPCB quality mark | No |
| Zeta value branch fluent separation according to DVGW W 575 | 0.0000 |
| Zeta value gangway current separation according to DVGW W 575 | 0.0000 |
| Zeta value counter current separation according to DVGW W 575 | 0.0000 |
| Zeta value branch merging flow according to DVGW W 575 | 0.0000 |
| Zeta value passage merging flow according to DVGW W 575 | 0.0000 |
| Zeta value counter merging flow according to DVGW W 575 | 0.0000 |
