| Label | Value |
|---|---|
Outer pipe diameter connection 2 | 50mm |
Main colour fitting | Other |
Wall thickness, connection 2 | 4.5mm |
Bend angle | 0° |
Surface treatment connection 2 | Untreated |
Wall thickness, connection 1 | 4.5mm |
System-specific | Yes |
Length of connection 2 | 55mm |
Material connection 2 | Brass |
With de-aerator | No |
With sealing rings/gaskets | Yes |
DVGW quality mark for water | Yes |
With drain valve | No |
Medium temperature (continuous) | 0 - 85 |
Length | 99mm |
Standard Dimension Ratio (SDR) | 0 |
Surface treatment connection 1 | Untreated |
With thermal insulation | No |
Working length connection 1 | 17mm |
Material sealing | Ethylene-propylene diene monomer rubber (EPDM) |
KIWA certified | Yes |
Bend radius | 0mm |
Surface protection connection 1 | Untreated |
High tensile strength | Yes |
ETIM Classification | EC003024 |
DVGW quality mark for gas | No |
Reducing | No |
Shape | Straight |
Connection 1 | Press sleeve |
Max. operating pressure at max. medium temperature | 6bar |
Wrench width | 0mm |
Eccentric | No |
Max. operating pressure at 20 °C | 10bar |
Material connection 1 | Brass |
DIN-CERTCO certificate | No |
Connection 2 | Press sleeve |
Zeta value | 0.9 |
Surface protection connection 2 | Untreated |
Material quality connection 2 | Other |
Model | 1-part |
Nominal diameter connection 2 | DN 40 |
Nominal diameter connection 1 | DN 40 |
Material quality connection 1 | Other |
Working length connection 2 | 12mm |
Capped | No |
Outer pipe diameter connection 1 | 50mm |
Contour code connection 1 | U |
Length of connection 1 | 55mm |
Gastec QA mark | No |
Wrench width union nut | 0mm |
Contour code connection 2 | U |
With buffer stud | Yes |
| Label | Value |
|---|---|
VVS nr. | 88155350 |
